Apple iPhone 11 Pro Max Rear Complete Body Housing Replacement, White - Verified Fit

About this product

This is a complete rear body housing replacement built specifically for the Apple iPhone 11 Pro Max, the 2019 model with a 6.5-inch OLED display and a glass front/back design set into a stainless steel frame. It is intended to replace a cracked, dented, or water-damaged rear housing on the same chassis, restoring the device's original 158.0 x 77.8 x 8.1mm profile and 226g weight rather than adding bulk on top of it. Because the iPhone 11 Pro Max's rear glass also serves as the surface for its wireless charging coil, the housing is shaped to keep that panel unobstructed once fitted. The cutouts, seams, and button openings are laid out to match this exact model's hardware, not a generic "iPhone 11" template.

• Camera cutout aligned to the triple 12MP + 12MP + 12MP rear lens array (Ultra Wide, Wide, Telephoto)
• Full rear glass panel sized for wireless charging use, matching the stock Qi-compatible back
• Lightning charging port opening at the base, matching the device's Lightning connector
• Side button and mute-switch openings positioned for the stainless steel frame edge
• 158.0 x 77.8 x 8.1mm profile matched to the original iPhone 11 Pro Max dimensions

How it fits your Apple iPhone 11 Pro Max

Once installed, the housing sits flush against the device's stainless steel frame, keeping the finished depth close to the stock 8.1mm and the overall weight near the original 226g, so the phone doesn't feel noticeably thicker or heavier in hand afterward. The triple camera cutout is cut to the spacing of the 12MP wide, 12MP ultra-wide, and 12MP telephoto lenses, so the array sits inside its opening without the lenses touching the housing edge. The base cutout is positioned for the Lightning port, and the volume and side buttons line up with the stainless steel frame's button wells so they still travel and click normally through the housing. Because this is a rear housing and not a screen component, it does not touch the 6.5-inch OLED panel or its scratch-resistant glass at the front, so that protection is unaffected by this replacement. The original device carries an IP68 water resistance rating from Apple's factory seals; a replaced rear housing is not resealed to the same factory standard, so treat the phone as no longer verified water resistant after the swap.

What you should know

This housing is built for the Apple iPhone 11 Pro Max only, and it is not sized for the standard iPhone 11 Pro (5.8-inch), the iPhone 11, or the iPhone XS Max, all of which use different frame dimensions or camera layouts despite looking similar at a glance. White is not one of Apple's original color options for this model (the factory colors are Space Gray, Silver, Gold, and Midnight Green), so this is an aftermarket color choice rather than a factory-matched finish, worth knowing if you're trying to keep the phone looking stock. This is a structural and cosmetic replacement part, not a snap-on protective case: it replaces the phone's actual back panel and frame section rather than adding a protective layer over the existing one, so it corrects damage but doesn't provide extra shock absorption beyond what the original design offered. Fitting a rear housing involves opening the device and transferring internal components, including the wireless charging coil and antenna lines, so we recommend professional installation rather than a DIY attempt, and you should note that opening the device yourself may affect any remaining manufacturer warranty and, as mentioned, the factory IP68 water resistance rating.

Buying with confidence

Dastyab.pk offers a 7-day return on unused, uninstalled items if this housing isn't right for your device, and we deliver across Pakistan. This listing states only what's confirmed for the Apple iPhone 11 Pro Max's own specifications, with no invented certifications or ratings, so you know exactly what you're fitting before you open the phone.
