Apple iPhone 16 Pro Max Gray Back Battery Door with Camera Lens Glass

About this product

This is a replacement back battery door assembly with integrated camera lens glass, built for the Apple iPhone 16 Pro Max only. The Pro Max ships with a 6.90-inch OLED display protected by Ceramic Shield up front and a titanium frame wrapped around a textured matte glass back — this part reproduces that rear glass and frame section, in a Gray finish, for phones where the original back glass has cracked or shattered around the camera housing. Because the Pro Max measures 163.0 x 77.6 x 8.25mm and weighs 227g, the replacement door is molded to those exact external dimensions so the phone keeps its original silhouette and hand feel after the swap. It carries pre-cut openings for every rear-facing feature on this model, so a technician is not left drilling or trimming glass on the bench.

• Camera lens glass cut for the 48MP + 48MP + 12MP triple rear camera array
• Cutout positioned for the MagSafe magnet ring used for wireless charging and MagSafe accessories
• Base opening matched to the USB-C charging port
• Side cutouts for the Action button and Camera Control button
• Frame profile matched to the titanium mid-frame construction
• Gray finish designed to sit against the device's factory color

How it fits your Apple iPhone 16 Pro Max

Every cutout on this door is positioned against the Pro Max's actual hardware layout, not a generic Pro-series template. The triple 48MP + 48MP + 12MP camera block sits inside a reinforced square housing at the top left of the back glass, and the lens glass openings here line up with that exact arrangement, including the raised ring around the housing. The port cutout at the bottom edge is sized for the iPhone 16 Pro Max's USB-C connector, and the internal contact area for MagSafe is positioned to keep 25W wired and MagSafe wireless charging functioning normally once the door is fitted with a working coil and connector transferred from the original unit. The Action button and Camera Control button cutouts on the frame edge sit where Apple placed them on this model, so button caps from the original housing transfer across without binding. Because the stock IP68 rating depends on the adhesive gasket run around this exact door, not the glass itself, the seal quality after installation is determined by the adhesive and technique used, not by this part alone.

What you should know

This door is cut for the Apple iPhone 16 Pro Max only — it does not fit the iPhone 16 Pro (6.3-inch chassis), the iPhone 16 or iPhone 16 Plus (different camera housing and dimensions), or the iPhone 15 Pro Max (different frame tooling from the prior generation). The Gray finish is an aftermarket color match, not one of Apple's four official titanium finishes (Black, White, Natural, or Desert Titanium), so compare it against the phone in hand if an exact factory match matters to you. This part is the outer glass-and-frame housing only: it does not include the 4685mAh battery cell, camera modules, wireless charging coil, or any flex cables, which must be transferred from the original back door or sourced separately. It restores the phone's structural housing and cosmetic finish; it is not an added layer of drop or scratch protection beyond the original design. Fitting a battery door involves full disassembly around the battery and internal cabling, so we recommend professional installation — incorrect handling at this stage can damage the battery, affect the water-resistance seal, or affect your device's warranty status.

Buying with confidence

Dastyab.pk accepts 7-day returns on unused, uninstalled items in original condition, and we deliver Pakistan-wide. This listing is written and checked against the Apple iPhone 16 Pro Max's own published specifications, so what you read here is what the part is cut to fit.
