Infinix Hot 10s Purple Middle Frame Housing with Camera Lens - Verified Fit

About this product

This is a complete middle frame housing for the Infinix Hot 10s, replacing the phone's structural mid-frame, side buttons, and rear camera lens cover in one assembly. It is built for a device with a 6.82-inch IPS LCD display, a plastic back over a plastic frame, and dimensions of 171.8 x 78.3 x 8.9mm at 207g, so the frame's screw bosses, button wells, and lens ring are shaped to match those exact measurements rather than a generic universal mold. The Purple finish corresponds to the 7 Degree Purple colorway Infinix shipped on the Hot 10s, so the shade and light reflection match the factory original rather than approximating it. This part is meant for phones with a damaged, cracked, or bent frame, snapped side buttons, or a scratched or broken camera lens cover, not as a cosmetic overlay.

• Pre-formed lens ring sized for the 48MP + 2MP + AI triple-lens rear camera array
• Side button cutouts aligned to the Hot 10s's physical volume and power button travel
• Frame depth matched to the phone's 8.9mm profile and 207g plastic-back build
• Port opening positioned for the micro-USB charging port (10W wired charging; no wireless coil cutout needed since the Hot 10s has no wireless charging)
• Dual Nano-SIM tray slot cut to the original tray opening
• Retains the 3.5mm headphone jack opening on the frame

How it fits your Infinix Hot 10s

Because the Hot 10s carries its 6000mAh battery and MediaTek Helio G85 board inside a plastic unibody-style shell, the middle frame is what the screen, battery, and motherboard actually screw into, so this replacement is dimensioned to the same 171.8 x 78.3 x 8.9mm chassis as the original part, not a rough approximation. The camera lens cutout is set for the rear 48MP main + 2MP depth + AI lens cluster, so the ring sits flush around all three without pressing on the glass. Side button wells are positioned for the Hot 10s's volume rocker and power key travel, and the SIM tray channel matches the phone's Dual Nano-SIM slot. The charging cutout is shaped for the micro-USB port used for the Hot 10s's 10W charging, not USB-C, so it will not fit a device with a USB-C port. Because this is a structural frame, not a screen protector, it does not add drop or scratch protection to the 90Hz display itself; it restores the housing that the display, battery, and buttons sit inside.

What you should know

This housing is made specifically for the Infinix Hot 10s and is not interchangeable with the Infinix Hot 10, Hot 10i, Hot 10 Play, Hot 10T, or Hot 11 series — those models use different frame dimensions, button placement, or camera layouts even though the names look similar. This part replaces the physical frame, side buttons, and lens cover only; it does not include the display, battery, motherboard, or rear camera modules, and it does not carry any drop-rating, water-resistance, or IP certification since Infinix does not list one for this model. Fitting a mid-frame housing means opening the phone, transferring the battery, board, buttons, and camera modules from the old frame, and reseating the SIM tray and connectors, which is a job for someone comfortable with phone disassembly or a phone repair technician — doing it yourself may affect any remaining manufacturer or seller warranty on the device, and a rushed reassembly risks damaging the flex cables around the camera or charging port. Handle the plastic frame carefully around the screw posts, as forcing a mismatched screw can strip the mounting point.

Buying with confidence

Dastyab.pk accepts returns within 7 days on unused, uninstalled items if this frame is not what your Hot 10s needs, and we deliver across Pakistan. This listing states only the compatibility and specifications confirmed for the Infinix Hot 10s, without added claims about certifications or ratings the device does not have.
