About this product

This is a direct-replacement middle frame with an integrated side button assembly and a matching battery back door, built specifically for the Infinix Hot 40i (2024), a 6.56-inch IPS LCD device with a 90Hz refresh rate and a plastic frame-and-back construction. The frame is molded to the phone's 163.7 x 75.1 x 8.5mm chassis, so the power and volume buttons sit in the same positions as the original hardware and respond with the same click travel. The battery back door is sized for the Hot 40i's 5000mAh battery compartment and carries the finished Golden color on its outer face. Because this replaces structural body panels rather than sitting over them, it restores the phone's shape and button function after a crack, snap, or lost back cover, not just its appearance.

Molded to the Hot 40i's exact 163.7 x 75.1 x 8.5mm frame dimensions
Side button cutouts positioned for the stock power and volume rocker
Back door sized to seat over the 5000mAh battery without added bulk
USB-C charging port cutout matched to the phone's 10W charging port
Camera housing cutout aligned to the 13MP + QVGA rear camera array
Golden finish on plastic construction matching the device's plastic frame-and-back build

How it fits your Infinix Hot 40I

The middle frame is dimensioned around the Hot 40i's own 163.7 x 75.1 x 8.5mm body and 193g weight, so once seated it doesn't add noticeable thickness or throw off the phone's balance in hand. The rear camera cutout is shaped for the Hot 40i's 13MP + QVGA dual-camera module, not a single-lens or triple-lens layout, so the opening lines up only with this generation's camera bump. The charging port cutout is cut for USB-C, matching the Hot 40i's 10W USB-C charging port, and the lower edge leaves clearance for the speaker grille and microphone. Side button inserts correspond to the phone's power key and volume rocker placement, and the SIM tray slot is cut for the Hot 40i's dual Nano-SIM tray. The top edge is left open around where the 6.56-inch IPS LCD display seats into the frame, and the 3.5mm headphone jack cutout on the base matches the device's built-in headphone port.

What you should know

This part is built for the Infinix Hot 40i only, it is not interchangeable with the Hot 40i Pro, Hot 30i, or other Hot-series models, which use different dimensions and camera layouts even when the naming looks similar. The Golden colorway is an aftermarket finish; Infinix's official Hot 40i colors are Starlit Black, Palm Blue, and Lime Green, so this will not be an exact factory color match if you're trying to restore an original-look device. This is a structural and cosmetic replacement, not a shock-absorbing or waterproof upgrade, the Hot 40i ships without an IP water-resistance rating, and this frame doesn't add one. Fitting a new middle frame and back door involves opening the phone and transferring internal components (motherboard, battery, buttons, SIM tray) from the old housing, which is a job we recommend leaving to a qualified phone repair technician; incorrect handling of the battery or internal ribbon cables can damage the device, and disassembly may affect any remaining manufacturer warranty on your unit.

Buying with confidence

Dastyab.pk ships this Infinix Hot 40i Golden middle frame and battery back door across Pakistan, and unused items can be returned within 7 days if the fit isn't right. The listing reflects the Hot 40i's actual published dimensions and camera configuration rather than generic casing copy, so what you see here is what the part is cut for.
