Oppo A15 Blue Middle Frame Housing With Camera Lens - Verified Fit
In stock
- SKU
- casing-00669
- Color
- Blue
Product Specifications
| Made of | Other |
|---|---|
| Accessory Type | Casing |
| Model | Oppo A15 |
| Items in Box | 1 x Body Casing For Oppo A15 |
| Color | Blue |
Product Description
About this product
This is a complete middle frame housing in Blue, built specifically to replace the structural chassis on the Oppo A15, the 2020 model with a plastic body measuring 163.6 x 75.4 x 8.2mm and weighing 182g. If your A15's frame is bent, cracked at the corners, or corroded around the charging port, this casing gives you a fresh structural shell rather than a cosmetic patch. The blue finish is matched to sit alongside Oppo's own Mystery Blue color option for this model, so a replacement doesn't look mismatched next to the original rear panel.
- Pre-fitted side buttons for volume and power, positioned to match the A15's original button travel
- Camera lens ring cut and aligned for the A15's triple rear array — 13MP main, 2MP depth, 2MP macro
- Micro-USB charging port cutout (the A15 uses Micro-USB, not USB-C)
- SIM tray channel sized for the A15's Dual Nano-SIM + microSD layout
- Battery bay dimensioned for the A15's 4230mAh battery
- Plastic construction consistent with the A15's original plastic-body build
How it fits your Oppo A15
Because this frame is built to the A15's 163.6 x 75.4 x 8.2mm footprint, the 6.52-inch IPS LCD display seats into the same lip and bezel the original panel used, and the frame doesn't add noticeable thickness or throw off the phone's 182g balance in the hand. The camera lens ring lines up with the 13MP + 2MP + 2MP rear cluster so the lenses sit flush rather than recessed or angled — a common issue with generic, non-model-specific frames. The Micro-USB cutout and side button housings match the A15's original port and button placement, so a technician isn't left filing plastic to make components fit. Oppo lists a splash-proof coating on the A15's original housing; this replacement frame will not automatically restore that coating once the device has been opened and rebuilt, which we cover below.
What you should know
This frame is verified for the Oppo A15 (2020) only — it is not sized for the Oppo A15s, A16, A16k, A5 2020, A9 2020, or A12, all of which use different dimensions, camera housings, or button placement despite similar model names. This is a structural and cosmetic housing, not a display, battery, or motherboard — it does not include the screen, battery, or internal circuitry, and it will not fix a cracked screen or a battery that no longer holds a charge on its own. Fitting this frame requires full disassembly of the phone, including disconnecting the battery, display flex, and camera modules, so we recommend having it installed by a professional technician rather than attempting it without repair experience; incorrect handling of internal ribbon cables can damage the device. Opening the device to replace the frame may affect any remaining manufacturer warranty, and because splash-proof coatings are factory-applied at assembly, we cannot claim the original splash resistance is fully preserved after a frame swap.
Buying with confidence
Dastyab.pk accepts returns within 7 days on unused, uninstalled items, and this listing (SKU casing-00669) has been checked against the Oppo A15's official specifications before publishing. We deliver across Pakistan, so you can order this frame with a clear picture of exactly what it does and doesn't cover before a technician opens your device.
