Vivo S1 Middle Frame Housing With Side Buttons, Camera Lens – Verified Fit

About this product

This is a replacement middle frame (chassis) for the Vivo S1, built to restore the structural core of a phone whose original frame has been bent, cracked, or corroded through drop damage or long-term wear. It's not a slip-on case — it's the internal frame that sits between the front Super AMOLED display and rear glass, carrying the pre-fitted camera lens ring, side button covers, and port cutouts that line up with the S1's 159.5 x 75.2 x 8.1mm body. Because the Vivo S1 pairs a 6.38-inch Super AMOLED panel with a glass front and back on a plastic mid-frame, a damaged frame usually shows up as a loose display, misaligned buttons, or a camera ring that no longer sits flush — this housing addresses that at the structural level rather than papering over it with an external shell.

• Camera lens cutout sized for the S1's 16MP+8MP+2MP triple rear camera stack
• Port cutout positioned for the Micro-USB charging port, rated for 18W input
• Side button housings for volume and power keys, matched to the 179g body's control layout
• Cutout consistent with the S1's dedicated microSD card tray, kept separate from the dual Nano-SIM slots
• Finished in black to pair with the Diamond Black colorway

How it fits your Vivo S1

Because the frame is dimensioned to the S1's exact 159.5 x 75.2 x 8.1mm footprint, it's built as a direct structural replacement rather than a universal fit — the screw bosses, speaker cutout, and earpiece channel are positioned to match the original tooling. The camera ring seats the 16MP+8MP+2MP rear array without pressing on the lens stack, and the front opening is sized for the 6.38-inch Super AMOLED display's 2340x1080 panel so the digitizer sits flush once reassembled. The Micro-USB port opening lines up with the 18W charging port at the base, and the side rails carry molded housings for the volume rocker and power button in the same position as the stock plastic frame. Because the S1 uses an in-display fingerprint sensor rather than a rear scanner, there's no fingerprint cutout on the back — that sensor lives in the display assembly, not the frame — while the dual Nano-SIM tray and microSD slot pass through their original channel unchanged.

What you should know

This housing is built for the Vivo S1 specifically — it is not intended for the Vivo S1 Pro, Vivo Y17, Vivo Z1 Pro, or any other Vivo model, since frame dimensions, button placement, and camera cutouts differ across those devices even where design language overlaps. This is a structural replacement part, not a decorative accessory: it restores frame integrity and cutout alignment, but it does not include the display, battery, camera modules, or charging flex — those parts transfer from your original device during the repair. Installation involves a full disassembly of the phone and is not a snap-on job; because it touches the display seal, battery cradle, and charging assembly, we recommend professional installation, and opening the device may affect any remaining manufacturer warranty. As with any composite replacement frame, expect the fit to match the S1's factory tolerances closely but treat it as an aftermarket part rather than an OEM Vivo component, and check screw hole alignment during reassembly before fully securing the display.

Buying with confidence

Dastyab.pk backs this listing with a 7-day return policy on unused, uninstalled items, so you can inspect the frame against your S1 before committing to a full teardown. We ship this middle frame housing across Pakistan, and the listing is scoped to the Vivo S1 (SKU casing-01659) specifically rather than a generic multi-model compatibility claim, so what you receive is dimensioned for the phone you actually own.
